206-26-71480 Planet Carrier Gear

Name: 2062671480 Planet Carrier Gear
Brand: MENZEH GEARS
Price: 1 USD

Wholesale 206-26-71480 Planet Carrier Gear from china suppliers

Brand Name : MENZEH GEARS

Model Number : 206-26-71480 20Y-26-21150 206-26-71471

Certification : CE

Place of Origin : GUANGZHOU CHINA

MOQ : 1 sets

Price : Negotiated

Payment Terms : Western Union, T/T, L/C, ALIPAY

Supply Ability : 1000 pcs per Day

Delivery Time : 1-3 working Days

Packaging Details : Wooden Case

Part Name : Swing 2nd Assy

Part Number : 206-26-71480 20Y-26-21150 206-26-71471

Used For : PC220-7 PC240-10 PC220-8

Condiction : OEM, Aftermarket

Warrenty : 6 Months, 1 YEAR

Shipping : Express / SEA/ AIR Shipping

Port : Huangpu, Guangzhou

High Light : Swing 2nd Carrier Assy，Repaired Parts

Weight : 16 kgs with Packing

Contact Now

206-26-71480 20Y-26-21150 206-26-71471 PC220-7 PC240-10 PC220-8 Swing 2nd Assy

Pos.	Part No	Qty	Parts name	Comments
1	22U-26-21280	[1]	Ring Komatsu	0.001 kg.
	["SN: 90001-UP"] analogs:["20Y2622270"]
2	07042-00312	[1]	Plug, Taper Komatsu	0.031 kg.
	["SN: 90001-UP"] analogs:["0704210312"]
3	206-26-73310	[1]	Case Komatsu	92 kg.
	["SN: 90001-UP"]
4	206-26-73150	[1]	Bearing Komatsu	4.64 kg.
	["SN: 90001-UP"]
5	206-26-73160	[1]	Bearing Komatsu China	12.5 kg.
	["SN: 90001-UP"]
6	206-26-73130	[1]	Shaft Komatsu	30.42 kg.
	["SN: 90001-UP"]
7	206-26-73140	[1]	Spacer Komatsu	0.86 kg.
	["SN: 90001-UP"]
8	07000-15100	[1]	O-Ring Komatsu China	0.01 kg.
	["SN: 90001-UP"] analogs:["YM24311001000", "0700005100"]
9	20Y-26-22420	[1]	Seal Komatsu China	0.3 kg.
	["SN: 90001-UP"]
10	206-26-73120	[1]	Cover Komatsu China	4.4 kg.
	["SN: 90001-UP"]
11	01010-81040	[12]	Bolt Komatsu	0.288 kg.
	["SN: 90001-UP"] analogs:["0101051040", "R0101081040"]
12	01643-31032	[12]	Washer Komatsu	0.054 kg.
	["SN: 90001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
13	07000-15310	[1]	O-Ring Komatsu China	0.035 kg.
	["SN: 90001-UP"] analogs:["0700005310"]
14	206-26-71480	[1]	Carrier Komatsu	10.88 kg.
	["SN: 90001-UP"]
15	206-26-71440	[4]	Gear Komatsu	1.91 kg.
	["SN: 90001-UP"]
16	22U-26-21320	[8]	Bearing Komatsu	1.1 kg.
	["SN: 90001-UP"]
17	206-26-71520	[8]	Washer, Thrust Komatsu	0.1 kg.
	["SN: 90001-UP"]
18	206-26-71510	[4]	Pin Komatsu	0.97 kg.
	["SN: 90001-UP"]
19	20Y-26-21330	[4]	Pin Komatsu China	0.1 kg.
	["SN: 90001-UP"]
20	20Y-26-21240	[1]	Plate Komatsu	5.1 kg.
	["SN: 90001-UP"]
21	112-32-11211	[1]	Bolt Komatsu	0.09 kg.
	["SN: 90001-UP"]
22	206-26-71452	[1]	Gear Komatsu	28.79 kg.
	["SN: 90001-UP"]
23	20K-22-11190	[1]	O-Ring Komatsu	0.02 kg.
	["SN: 90001-UP"] analogs:["20G2211190"]
24	01010-81440	[22]	Bolt Komatsu	0.073 kg.
	["SN: 90001-UP"] analogs:["0101061440", "0101031440", "0101051440", "0104031440"]
25	01643-31445	[22]	Washer Komatsu	0.019 kg.
	["SN: 90001-UP"] analogs:["0164301432"]
26	206-26-71430	[1]	Gear Komatsu	2.33 kg.
	["SN: 90001-UP"]
27	04260-01270	[1]	Ball Komatsu OEM	0.009 kg.
	["SN: 90001-UP"]
28	206-26-71471	[1]	Carrier Komatsu	3.9 kg.
	["SN: 90001-UP"] analogs:["2062671470"]
29	206-26-71420	[3]	Gear Komatsu	0.83 kg.
	["SN: 90001-UP"]
30	20Y-27-22210	[3]	Bearing Komatsu China	0.12 kg.
	["SN: 90001-UP"] analogs:["20Y2721260"]
31	22U-26-21230	[6]	Washer, Thrust Komatsu	1 kg.
	["SN: 90001-UP"]
32	206-26-71210	[3]	Pin Komatsu	0.42 kg.
	["SN: 90001-UP"]
33	04064-03515	[6]	Ring Komatsu	0.005 kg.
	["SN: 90001-UP"]
34	206-26-71350	[1]	Holder Komatsu	0.21 kg.
	["SN: 90001-UP"]
35	206-26-71410	[1]	Gear Komatsu	0.83 kg.
	["SN: 90001-UP"]
36	206-26-71341	[1]	Plate Komatsu China
	["SN: 90001-UP"]

206-26-71480 Planet Carrier Gear

FAQ:
1. If I only know the excavator model, but can not offer parts No., what should I do ?
If possible, you can send us pictures of old products, nameplate or the measurement for reference, or we would supply you parts picutres, sizes for your confirmation.
2. What is the warranty of the parts after I purchased?
The warranty is 6/12 Months based on the item details.
3. How can I pay the order?
We can receive payment through T/T, Paypal(for small amount),Alibaba trade assurance.
4. When will get the items after I place order?
Once your payment is confirmed, we will arrange the goods in 1-3 working days; if not in stock , we will inform you before placing the order.
5. How can I do if there is something wrong with the items?
First of all, we have full confidence in our professional knowledges, and we also supply experienced engeerneers checking before sending parts to you, if still have answers, please supply us pictures or vedio for further checking and confirmation, after we confirmed us wrong, we would supply you parts freely, or return parts to us, or other mathoths to save costs during fixing...
6. What is your main products ?
We are specialized in the excavator gear parts, such as travel gearbox/ass'y/parts, swing gearbox/ass'y. If you need other excavator parts, we also can supply as your requirements.
